T通用轴向型膨胀节
作者 Admin
浏览
发布时间 2011-06-30
| |
 |
 |
| |
| 技术参数 |
公称通径
mm |
波数 |
轴向补偿器mm/轴向刚度N/mm |
有效面积
cm2 |
接管尺寸 |
产品长度
mm |
| 0.25MPa |
0.6MPa |
1.0MPa |
1.6MPa |
2.5MPa |
| 100 |
4 |
23/230 |
18/257 |
15/417 |
12/720 |
9.6/1126 |
147 |
Ø108×6 |
300
|
| 8 |
46/115 |
13/128 |
30/209 |
24/360 |
19/563 |
380 |
| 125 |
4 |
24/270 |
20/300 |
16/494 |
11/1206 |
9/1894 |
1920 |
Ø133×6 |
300 |
| 8 |
48/135 |
40/150 |
32/247 |
22/603 |
18/897 |
380 |
| 150 |
4 |
24/275 |
20/315 |
16/514 |
11/1606 |
9/2294 |
272 |
Ø159×6 |
300 |
| 8 |
48/138 |
40/158 |
32/257 |
22/803 |
18/1147 |
380 |
| 200 |
4 |
40/210 |
28/344 |
21/594 |
20/979 |
14/2246 |
498 |
Ø219×8 |
380 |
| 8 |
80/105 |
56/172 |
42/297 |
40/490 |
28/1123 |
500 |
| 250 |
4 |
40/264 |
30/416 |
28/488 |
20/1726 |
14/2308 |
764 |
Ø273×8 |
380 |
| 8 |
80/132 |
60/208 |
56/244 |
40/863 |
28/1154 |
500 |
| 300 |
4 |
46/220 |
35/432 |
27/780 |
21/1788 |
17/3494 |
1051 |
Ø325×8 |
430 |
| 8 |
92/110 |
70/216 |
54/390 |
42/894 |
34/1747 |
580 |
| 350 |
4 |
46/238 |
35/454 |
27/892 |
21/1864 |
17/3562 |
1326 |
Ø377×8 |
430 |
| 8 |
92/119 |
70/227 |
54/446 |
42/932 |
34/1781 |
580 |
| 400 |
4 |
46/262 |
35/495 |
27/1123 |
21/1633 |
17/4359 |
1613 |
Ø426×8 |
430 |
| 8 |
92/131 |
70/248 |
54/562 |
42/817 |
34/2180 |
580 |
| 450 |
4 |
52/290 |
36/527 |
28/1168 |
24/1957 |
19/4886 |
2025 |
Ø478×8 |
430 |
| 8 |
104/145 |
56/264 |
56/584 |
48/979 |
38/2443 |
580 |
| 500 |
4 |
55/312 |
37/862 |
32/1028 |
25/1871 |
20/4175 |
2348 |
Ø530×10 |
430 |
| 8 |
110/156 |
74/431 |
64/514 |
50/936 |
40/2088 |
580 |
| 600 |
4 |
70/270 |
48/730 |
36/1561 |
27/2908 |
23/5114 |
3452 |
Ø630×10 |
580 |
| 8 |
140/135 |
97/365 |
72/781 |
54/1454 |
46/2557 |
820 |
| 700 |
4 |
88/268 |
64/726 |
40/1643 |
32/2995 |
|
4880 |
Ø720×10 |
580 |
| 8 |
132/178 |
96/484 |
60/1695 |
48/1996 |
|
700 |
| 800 |
4 |
88/268 |
54/852 |
40/1808 |
35/2882 |
|
6197 |
Ø820×10 |
580 |
| 6 |
132/188 |
81/568 |
60/1205 |
52/1921 |
|
700 |
| 900 |
4 |
98/268 |
54/962 |
40/2034 |
32/3266 |
|
7701 |
Ø920×10 |
680 |
| 6 |
147/178 |
81/641 |
60/1356 |
48/2177 |
|
700 |
| 1000 |
4 |
96/293 |
54/790 |
41/2019 |
32/3269 |
|
9335 |
Ø1020×10 |
680 |
| 6 |
147/195 |
81/527 |
62/1346 |
48/2446 |
|
800 |
| 1100 |
4 |
110/309 |
63/1007 |
60/2252 |
53/3229 |
|
11163 |
Ø1120×12 |
680 |
| 1200 |
4 |
110/316 |
68/1065 |
65/1995 |
54/3318 |
|
13154 |
Ø1220×12 |
680 |
| 1300 |
4 |
110/368 |
72/1071 |
65/2038 |
54/3452 |
|
15221 |
Ø1320×12 |
680 |
| 1400 |
4 |
124/333 |
74/1025 |
65/1995 |
56/3650 |
|
17509 |
Ø1420×12 |
680 |
| 1500 |
4 |
124/358 |
72/1184 |
65/2072 |
56/4558 |
|
19933 |
Ø1520×14 |
700 |
| 1600 |
4 |
124/395 |
72/1264 |
65/2177 |
|
|
22486 |
Ø1620×14 |
700 |
| 1800 |
4 |
132/408 |
72/1423 |
54/2857 |
|
|
28055 |
Ø1820×16 |
700 |
| 2000 |
3 |
93/592 |
68/1555 |
52/3308 |
|
|
33240 |
Ø2020×18 |
725 |
| 2200 |
3 |
93/652 |
71/1663 |
52/3646 |
|
|
41112 |
Ø2220×18 |
725 |
| 2400 |
3 |
93/713 |
71/1817 |
50/3824 |
|
|
48612 |
Ø2420×18 |
725 |
| 2500 |
3 |
93/847 |
71/1883 |
50/4037 |
|
|
53257 |
Ø2520×20 |
725 |
| 2600 |
3 |
93/926 |
71/2045 |
50/4452 |
|
|
57425 |
Ø2620×20 |
725 |
| 2800 |
3 |
95/1180 |
65/2430 |
47/5887 |
|
|
66324 |
Ø2820×20 |
725 |
| 3000 |
3 |
95/1376 |
65/2593 |
47/6288 |
|
|
75672 |
Ø3020×20 |
725 |
| 3200 |
3 |
80/2387 |
60/2753 |
47/6689 |
|
|
85738 |
Ø3220×20 |
725 |
| 3400 |
3 |
80/2590 |
60/2915 |
47/7092 |
|
|
96432 |
Ø3120×20 |
725 |
| 3500 |
3 |
80/2690 |
60/2998 |
47/7293 |
|
|
102014 |
Ø3520×20 |
725 |
| 4000 |
3 |
80/3983 |
60/5203 |
|
|
|
132929 |
Ø4020×20 |
725 |
|
